QT4-20 Cheap Startop China Concrete Solid Hollow Paver Brick Block Making Machine for Sale Factory Price

This product is currently out of stock and unavailable. SKU: QT4-20 Cheap Startop China Concrete Solid -35655085 Category: Automatic block machine Description Additional information Table of ContentsDescriptionAdditional informationRelated productsBuilding Material Machinery Eco Premium 2700 Brick Making Machinery for Small BusinessYOUJU QT4-15 Concrete Block Moulds Factory Interlocking Paving Hollow Block Machine Bricks Manufacturing Automatic Block MakingQT4-16 […]

  • European-Patented Airbag Damping System
  • Four-Motor Synchronous Vibration Technology
  • Siemens PLC Smart Control · Lifetime Tech Support
  • Customized Solution for Local Materials & Voltage
Request Best Price → WhatsApp Chat
Lead Time
30 days
Warranty
12 mo
Sold
500+
Technical Excellence

Engineered for performance, built to last

Every parameter is verified through rigorous factory testing. No exaggeration -- just real production capacity backed by 320+ engineers.

Production Capacity
14,400 blocks/8h
Cycle Time
15-20 seconds
Total Power
88 kW
Operators
2-3 people

Product Description

Product Description
Overall Dimension
7100*1600*2610mm
Rated Pressure
16-21MPa
Main Vibration Form
Platform Vibration
Vibration Frequency
4600 ( r/min)
Pallet Size
950*500mm
Molding cycle
15-25 (s)
Overall Power
27.5W
Function and instruction
QT4-20 block making machine of our company is professional equipment for building blocks and bricks. Sand and cement can be mixed with flyash. slag. gangue or other industrial waste residue as material. Different kinds of specifications of hollow block and bricks like pavers. grass growing block. curbstone and standard bricks can be produced by changing the mould. The equipment is driven by hydraulic system and monitored by Non-contact proximity switch. collecting machine. electricity. light. hydraulic and high-frequency vibration technology as one unit. electrical and hydraulic appliance in the equipments are all from overseas or domestic famous brand.

  • advantage and feature

QT4-20 has the following features: tight structure. reliable function. easy operation. high efficiency. little malfunction. simple
maintenance. Block is formed mainly in hydraulic way and then by mechanical way. finished by vibration and pressing. The strength
of extension of finished products can reach 15Mpa or above with high density degree. good feature of anti-freezing and
anti-permeability. sound insulation and heat preservation. and accurate overall dimension. So QT4-20 block making machine is ideal
environmental protection and building materials equipment.
Detailed Images
different sides of QT4-20 semiautomatic concrete block machine
common blocks capacity and samples
Type
Size (mm)
Molding cycle
Qty/Mould (pcs)
Qty/hour (pcs)
Qty/8hr (pcs)
Hollow brick

400x200x200

20-30s

4

480-720

3840-5760
Hollow brick

400x150x200

20-30s

5

600-900

4800-7200
Hollow brick

400x100x200

20-30s

8

960-1440

7680-11520
Paver blocks

200x100x60

20-30s

16

1920-2880

15360-23040
Solid blocks

240x115x53

20-30s

28

3360-5930

26880-47440
Related Products
Packing&Shipping
the block machine is fixed into the container by steel
it need use 40ft high container to load
After Sales Service
after sales service ways
1.7×24 hours service
2.within 24 hours offer solve ways.
3.online video face to face service
4.local service. if necessary we can sent our engineer fly to customer site for guiding installation and train operation.
5.free spare parts.
Company Introduction
Shandong shiyue intelligent machinery CO.. LTD is the leading supplier of concrete machinery and plant . We have two factory areas covering more than 200.000 square meter areas .more than 50000 square meter workshops . more than 300 rich experienced engineers and technical persons. Our machine are well applied to more than 108 countries and areas. We customize different kinds of machine according to customers' local requests rather than just promote localized products to overseas clients from all over the world. We firmly believe"quality creates value. profession accomplishes success".
Customer Visiting and customer working site
FAQ
1> Is this block machine suitable for us to use?
Answer:Could you pls tell us the investment plan?the capacity you want?what kind of bricks do you want to make?Then the most suitable model will be recommended to you.
2>Which industry did this block machine usually be used in?
Answer: Hollow Block.Muticelullar bricks.Paving bricks.Standard bricks.etc
3>How to use the block machine?
Answer: We will send the operating manual to you or arrange engineer fly to your site for installation and training after you
purchase the machine.
4>How about the after sale service of block machine?
Answer: 1 year guarantee for the whole machine (without the spare parts).good machine no need after sale service.we keep the superior quality machine for you.
5>what's your payment term?
Answer:our common payment is 30% deposit by T/T before arrange the machine production.70% balance before the delivery.if other payment term.we can negotiation.
