Description
Fast dispatch, matched to your site — the QT5-15 stationary block machine is stocked and configured against your local aggregate and target block format before container loading.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | QT5-15 |
| Product Type | Hydraulic PLC Controlled Block Making Machine |
| Overall Dimensions (L×W×H) | 7400×1950×2800 mm |
| Rated Pressure | 21 MPa |
| Main Vibration Form | Platform Vibration |
| Vibration Frequency | 2800–4500 r/min |
| Pallet Size | 1100×550 mm |
| Molding Cycle | 15–25 s |
| Overall Power | 26.5 kW |
| Demolding Method | Hydraulic |
| Control System | PLC Controlled |
| Automation Level | Automatic Gear-Driven |
| Output: Hollow Brick 400×200×200 mm | 1800 pcs/h (based on 5 pcs/mold, 16–20 s cycle) |
| Output: Hollow Block 400×150×200 mm | 1300 pcs/h (based on 6 pcs/mold, 15–20 s cycle) |
| Output: S Paver 225×112.5×60 mm | 3700 pcs/h (based on 16 pcs/mold, 15–17 s cycle) |
| Raw Materials | Crushed stone, sand, cement, dust, fly ash, gravel, slag |
| Voltage & Frequency | (basis to be confirmed) |
| Net Weight | (basis to be confirmed) |
| Mould Change Time | (basis to be confirmed) |
| Stacking Method | (basis to be confirmed) |
Application Suitability
| Application | Material or Output |
|---|---|
| Housing project block supply | Hollow and solid concrete blocks from crushed stone and cement |
| On-site contractor production | Interlocking blocks and kerbstones from locally sourced sand and gravel |
| Paver manufacturing for distribution yards | S pavers and colored pavers from fine aggregate and fly ash blends |
| Regional building material restocking | Multiple block formats on a single machine with mould swaps |
| First plant launch by entrepreneurs | Semi-automatic to automatic operation across hollow block and paver formats |
What "In Stock" Actually Means When the Deadline Is Real
A stocked QT5-15 ships when your project schedule demands it, not when a production slot opens up.
I have watched project contractors lose weeks because the machine they ordered was still in a production queue while their foundation crew sat idle. A stationary block machine in stock with confirmed dispatch lead time removes that gap. The QT5-15 is available for container loading now, with pallet and mould configuration locked before it leaves the factory floor so commissioning does not stall over a voltage mismatch or a PLC screen displaying the wrong language [NEED_CITE: voltage and frequency standards by export market].
Dispatch Readiness Without Configuration Guesswork
The fast delivery QT5-15 leaves the warehouse with its hydraulic pressure and vibration frequency already tuned to a known mix design. Before loading, the factory test record confirms the machine cycles within its stated molding range on the block format you specified. This is the difference between a machine that runs on day one and one that needs a technician rewriting parameters while your curing racks sit empty.
Container Loading and Dismantling for Transit
The QT5-15 ships with the main frame, hydraulic station, and PLC cabinet separated for container fit. Each sub-assembly is bolted, not welded, so reassembly on-site follows a documented sequence rather than requiring field fabrication. Pallets ship flat-stacked in the same container to keep the first production run within reach the moment the machine is powered up.
Reading the Specs That Decide Your Daily Output
Platform vibration at 2800–4500 r/min paired with 21 MPa hydraulic pressure determines whether your hollow blocks come off the pallet dense enough to meet structural load requirements or crumble at the edges during handling. The 1100×550 mm pallet size must match your existing curing rack spacing and forklift tine width — a mismatch here means either buying new racks or losing pallet positions per cycle. The PLC control system governs the 15–25 s molding cycle and needs its display language and voltage confirmed before the machine is crated, not after it arrives at a 415 V site wired for 380 V [NEED_CITE: common commissioning delays from unconfirmed electrical specifications].
The Cost of Skipping the Configuration Conversation
A machine quoted without confirming your local aggregate grading and cement type will arrive set for a mix you cannot source. I spent three days on a site in Southeast Asia retuning vibration frequency and hydraulic pressure because the stone powder had a clay content the original configuration never accounted for —成型率 dropped to less than half of what the capacity table showed. That kind of field rescue is avoidable when the configuration conversation happens before the machine is pulled from stock [NEED_CITE: impact of local aggregate variation on block density and成型 yield].
Why Buyers Source the QT5-15 Here
Block machinery is our single focus, so the QT5-15 ships as a matched system — machine, mould, pallet, and handling equipment specified together rather than assembled from unrelated suppliers. Mould design covers the formats your market actually buys, and custom mould drawings are available when your local demand includes non-standard dimensions. The automation level is selectable, meaning you can start with semi-automatic pallet handling and upgrade to full stacking and cubing later without replacing the press. Capacity calculations state the block format assumed, so your daily output expectation matches reality from the first shift.
Documentation & Verification
- Factory test record on your specified block format and cycle time before dispatch
- Mould drawing and format list so you confirm dimensions match local market standards
- Voltage and PLC display language confirmation document signed off pre-shipment
- Line layout with capacity calculation tied to the exact block format you will produce
- Packing photographs showing container loading arrangement and sub-assembly separation
- Hydraulic and electrical schematic matching the as-built machine configuration
Installation, Commissioning & Support
- Foundation pad sized to 7400×1950 mm footprint with anchor bolt template provided
- Dedicated power circuit for 26.5 kW total draw with voltage confirmed before energizing
- Bolt-together reassembly from container-dismantled sub-assemblies, no field welding required
- PLC parameter set verified against your mix design during on-site commissioning
- Operator training covering mould change procedure and vibration frequency adjustment
- Wear parts and hydraulic seal list supplied with first-shipment spare kit
What to Include in Your Inquiry
Send us your target block format with dimensions, the daily output your project schedule requires, and a sample description of your local aggregate and cement source. Confirm your site voltage, frequency, and the language your operators need on the PLC display. If you have existing curing racks or forklifts, share the pallet dimensions they accommodate so the QT5-15 is configured to fit your yard, not the other way around.
Frequently Asked Questions
Q: Which stationary block machine models and moulds are currently in stock for immediate dispatch?
A: The QT5-15 is available from stock with standard hollow block and paver moulds ready for container loading. Custom moulds require a separate lead time for design and machining. We confirm current stock status and dispatch date at the point of inquiry so your project timeline is based on real availability, not an estimated production slot.
Q: What is the container loading plan and dispatch lead time for the QT5-15?
A: The machine is dismantled into main frame, hydraulic station, and PLC cabinet for container fit, with pallets flat-stacked in the same load. Dispatch lead time covers final factory testing, packing, and customs documentation preparation. We quote the arrival estimate from order confirmation to port delivery upfront so your site team can plan commissioning.
Q: How is voltage and PLC control language confirmed before the machine ships?
A: We request your site voltage, frequency, and preferred PLC display language during the inquiry stage. These are written into the confirmation document and verified during the factory test. The machine does not leave the floor until the electrical specification matches your destination site, preventing commissioning delays caused by a transformer swap or a screen your operators cannot read.
Q: Can the QT5-15 be dismantled for shipment and reassembled on-site quickly?
A: Yes. The main frame, hydraulic station, and control cabinet are bolt-connected sub-assemblies designed for container loading and field reassembly without welding. The reassembly sequence is documented, and all fastener specifications are included in the packing list so your installation team can work through the process without waiting for missing hardware.
